TNY286DG Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Tube
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 725V
Topology Flyback
Duty Cycle 67%
Switching Frequency 124kHz ~ 140kHz
Power (W) 13W
Fault Protection Current Limiting, Open Loop, Over Temperature, Over Voltage, Short Circuit
Control Features EN
Temperature Range - Operating -40°C ~ 150°C
Manufacturer Package 8-SOIC , 7 Leads
Supplier Device Package 8-SO
Mounting Style SMT
Manufacturer Pack Quantity 100
MSL Level 1 (Unlimited)
Win Source Part Number 1271572-TNY286DG
Manufacturer Homepage www.powerint.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TNY286DG CAD Model

Description

The TNY286DG is a Flyback topology integrated circuit that is designed by Power Integrations. It is packaged in an 8-SOIC, 7 Leads package and is mounted on the surface.

  • Topology: Flyback
  • Package: 8-SOIC, 7 Leads
  • Mounting: Surface
  • Switches: Internally equipped
  • Isolation: Isolated
  • Voltage Breakdown: 725V
  • Duty Cycle: 67%
  • Fault Protection: Current Limiting, Open Loop, Over Temperature, Over Voltage, Short Circuit
  • Control Features: EN
  • Switching Frequency Range: Between 124kHz to 140kHz
  • Maximum Power Dissipation: 13W
  • Commonly Used: In various applications
  • Available In: A pack of 100
