BRD1163C-TL Power Integrations
Same model may have multiple batches, images only for reference.

BRD1163C-TL

Part No BRD1163C-TL
Manufacturer Power Integrations
Catalog PMIC - Full, Half - Bridge Drivers
Description IC HALF BRIDGE DRVR 3A INSOP24C / Half Bridge Driver DC Motors, General Purpose Power MOSFET InSOP-24C
Datasheet
BRD1163C-TL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Full Half-Bridge Drivers
Mfr Power Integrations
Series BridgeSwitch
Package Tape & Reel
Product Status Active
Output Configuration Half Bridge
Applications DC Motors, General Purpose
Interface Analog, Logic, PWM
Load Type Capacitive and Resistive
Technology Power MOSFET
Rds On (Typ) 1.53Ohm LS, 1.53Ohm HS
Current - Output / Channel 3A
Current - Peak Output -
Voltage - Supply -
Voltage - Load 600V
Temperature Range - Operating -40°C ~ 150°C (TJ)
Features Bootstrap Circuit
Fault Protection Current Limiting, Over Temperature, Over Voltage
Mounting Type Surface Mount
Package / Case 24-PowerSMD Module (0.425", 10.80mm Width), 17 Leads
Supplier Device Package InSOP-24C
Base Product Number BRD1163
MSL Level 3 (168 Hours)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1357207-BRD1163C-TL
Ultra Librarian 3D Model Ultra Librarian BRD1163C-TL CAD Model

Description

The Power Integrations BRD1163C-TL is a full half-bridge driver IC from the BridgeSwitch series. It is designed for power management applications and operates in a wide temperature range from -40°C to 150°C.

  • Application: Power Management
  • Operating Temperature: -40°C ~ 150°C
  • Package / Case: Surface Mount
  • Bootstrap: Yes
  • Output Configuration: Half Bridge
  • Current - Output / Channel: 3A
  • Applications: DC Motors, General Purpose
  • Fault Protection: Current Limiting, Over Temperature, Over Voltage
