UCC27288DR

Part No UCC27288DR
Manufacturer Texas Instruments
Catalog PMIC - Full, Half - Bridge Drivers
Description 2.5-A TO 3.5-A 120-V HALF-BRIDGE / Half Bridge Driver DC Motors, General Purpose Power MOSFET 8-SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs)>PMIC - Full, Half-Bridge Drivers
Mfr Texas Instruments
Package Tape & Reel
Output Configuration Half Bridge
Applications DC Motors, General Purpose
Interface Logic, PWM, SPI
Load Type Inductive, Capacitive
Technology Power MOSFET
Current - Peak Output 3.5A, 2.5A
Voltage - Supply 8V ~ 16V
Voltage - Load 8V ~ 16V
Temperature Range - Operating -40°C ~ 140°C (TJ)
Features Bootstrap Circuit
Fault Protection Current Limiting, Short Circuit, UVLO
Mounting SMD (SMT)
Package / Case 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package 8-SOIC
Base Product Number UCC27288
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names 296-UCC27288DRTR,296-UCC27288DRCT,296-UCC27288DRDKR
Standard Package 2,500
Win Source Part Number 1145567-UCC27288DR
Ultra Librarian 3D Model Ultra Librarian UCC27288DR CAD Model

Description

The UCC27288DR from Texas Instruments is a robust, high-performance half-bridge gate driver designed to drive N-channel power MOSFETs and IGBTs. This driver is particularly well-suited for high-power applications that require efficient and reliable switching, such as power supplies, motor controllers, and inverter systems.

Key Features

  • High Peak Output Drive Capability: The UCC27288DR is capable of delivering high peak current to the gate of a power MOSFET, ensuring rapid and efficient switching. This results in improved overall system performance and reduced power losses.
  • Wide Supply Voltage Range: Operating from a supply voltage range of 10V to 20V, this driver is versatile and can be used in a variety of circuit configurations and applications.
  • Independent High-Side and Low-Side Output Channels: Each channel can be controlled separately, providing flexibility and precise control over the switching actions of the connected power devices.
  • 3.3V and 5V Logic Compatible: The input logic levels are compatible with both 3.3V and 5V logic, allowing for easy integration with a wide range of control circuits and microcontrollers.
  • High dV/dt Immunity: The UCC27288DR is designed to withstand high voltage transients, ensuring reliable operation even in harsh electrical environments.
  • Robust Design: With features such as under-voltage lockout and over-temperature protection, the driver ensures safe operation and protects the power devices and the system from damage.
  • Industry Standard Package: The device is offered in an 8-pin SOIC package, which is widely used in the industry and known for its reliability and ease of soldering.

Applications

The UCC27288DR gate driver is ideal for a range of high-power applications, including:

  • DC/DC Converters
  • AC/DC Power Supplies
  • Motor Drives
  • Inverters for Renewable Energy Systems
  • Class-D Audio Amplifiers
  • High-Power Lighting Systems

With its robust design and high-performance capabilities, the UCC27288DR from Texas Instruments is an excellent choice for engineers looking to enhance the efficiency and reliability of their power management systems.
