Part No MA2Q73600L
Manufacturer Panasonic
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 1A NMINIP2
Datasheet
MA2Q73600L Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Obsolete(EOL)
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 550mV @ 1A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 30ns
Current - Reverse Leakage @ Vr 2mA @ 40V
Capacitance @ Vr, F 50pF @ 10V, 1MHz
Mounting SMD (SMT)
Case / Package NMiniP2-J1
Operating Temperature - Junction -40°C to 125°C
Win Source Part Number 111437-MA2Q73600L
Ultra Librarian 3D Model Ultra Librarian MA2Q73600L CAD Model

Description

The MA2Q73600L is a Schottky diode belonging to the Discrete Semiconductor Products category. It has the following specifications:

  • Maximum DC Reverse Voltage: 40V
  • Average Rectified Current: 1A
  • Forward Voltage: 550mV @ 1A
  • Reverse Recovery Time: 30ns
  • Reverse Leakage Current: 2mA @ 40V
  • Capacitance: 50pF @ 10V, 1MHz
  • Package: Reel-TR
  • Operating Temperature Range: -40°C to 125°C
  • Speed: Fast Recovery = 200mA (Io)

This device is suitable for applications that require low forward voltage drop and low power consumption.
