ECP-U1E104JB5 Real Image
Same model may have multiple batches, images only for reference.

ECP-U1E104JB5

Part No ECP-U1E104JB5
Manufacturer Panasonic
Catalog Film Capacitors
Description CAP FILM 0.1UF 5% 25VDC 0805
Datasheet
ECP-U1E104JB5 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Capacitors
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Obsolete(EOL)
Capacitance 0.1μF
Tolerance ±5%
Voltage Rating - DC 25V
Dielectric Material Acrylic, Metallized
Temperature Range - Operating -40°C to 105°C
Mounting SMD (SMT)
Dimension 0.079" L x 0.049" W (2.00mm x 1.25mm)
Height - Seated (Max) 0.047" (1.20mm)
Termination Solder Pads
Applications General Purpose
Win Source Part Number 125369-ECP-U1E104JB5
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ECP-U1E104JB5 CAD Model

Description

ECP-U1E104JB5 Capacitor

The ECP-U1E104JB5 is an efficient capacitor renowned for its optimal balance between size and capacity, tailored for diverse electronic applications.

  • Capacitance: 100,000 μF
  • Voltage Rating: 25V
  • Temperature Range: -40°C to +105°C

Applications and Projects:

  • Switching power supplies
  • DC-DC converters
  • Photovoltaic energy systems
  • LED driver circuits

Features and Benefits:

  • High energy density with low impedance
  • Wide voltage operation range
  • Enhanced durability and lifespan
  • Small size facilitates compact design

This component is ideal for designs demanding both efficiency and compactness.
