Products specifications

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 60V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 720mV @ 1A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 200μA @ 60V
Mounting SMD (SMT)
Case / Package SMA
Operating Temperature - Junction -55°C to 150°C
Win Source Part Number 030819-SS16T3G
Family Name SS16
Introduction Date August 24, 2001
ECCN EAR99
Country of Origin Malaysia, Vietnam
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Automotive, Industrial
Ultra Librarian 3D Model Ultra Librarian SS16T3G CAD Model

Description

The ON Semiconductor SS16T3G is a high-performance Schottky barrier rectifier designed for applications requiring low forward voltage drop and high surge current capability. This rectifier is a popular choice in a wide range of electronic devices due to its efficiency and reliability. The SS16T3G is an ideal solution for power management tasks within consumer electronics, automotive systems, and industrial equipment.

Key Features

  • Low Forward Voltage Drop: With a maximum forward voltage of 0.5V at 1A, this Schottky rectifier ensures low power loss and improved efficiency in your circuits.
  • High Surge Capability: The device can handle a surge current of up to 40A, making it well-suited for applications with occasional high current demands.
  • Power Package: Encased in an SMB package, the SS16T3G is compact and suitable for surface-mount technology, allowing for efficient use of PCB space.
  • Reverse Voltage: It has a maximum repetitive reverse voltage of 60V, providing a good margin for typical low to medium voltage applications.
  • Operating Temperature: The rectifier operates over a wide temperature range from -55°C to +150°C, ensuring stability and performance under varying environmental conditions.
  • Lead-Free and RoHS Compliant: The SS16T3G adheres to environmental regulations, being lead-free and RoHS compliant, making it suitable for use in eco-friendly products.

Applications

The versatility of the ON Semiconductor SS16T3G Schottky barrier rectifier makes it well-suited for a variety of applications, including:

  • DC/DC converters
  • Power supply units
  • Automotive systems
  • Free-wheeling diodes in converters and motor control circuits
  • Reverse battery protection
  • LED lighting applications

In summary, the ON Semiconductor SS16T3G is a robust and efficient Schottky barrier rectifier that offers designers a compact, high-performance solution for rectification needs. Its low forward voltage drop, high surge current capability, and broad operating temperature range make it an excellent choice for a wide range of electronic applications.
