Product Overview: MURA160T3G - ON Semiconductor

The MURA160T3G is a high-performance surface mount Ultrafast Rectifier designed and manufactured by ON Semiconductor, a leading provider in the semiconductor industry. This component is engineered to meet the stringent requirements of high-efficiency power supply, lighting, and other power switching applications that demand fast switching characteristics and low power loss.

Key Features

• Ultrafast Reverse Recovery Time: With an ultrafast reverse recovery time (trr) typically under 50ns, the MURA160T3G is optimized for high-speed switching. This minimizes the power losses that occur during the transition from conducting to non-conducting states, enhancing overall circuit efficiency.
• High Surge Current Capability: This device can handle high surge currents, making it robust and reliable for applications with transient over-current conditions.
• Low Forward Voltage Drop: The low forward voltage drop (Vf) reduces conduction losses and contributes to the high efficiency of the rectifier in operation.
• Surface Mount Package: The MURA160T3G comes in a compact SMB package, suitable for automated surface mount assembly processes and saving valuable board space.
• RoHS Compliant: Complying with the Restriction of Hazardous Substances (RoHS) directive, this product is free from environmentally harmful substances, making it suitable for use in green electronics.

Applications

The MURA160T3G is versatile and can be used in a variety of applications, including:

• Switch-mode power supplies (SMPS)
• Power factor correction (PFC) circuits
• Automotive environments
• Freewheeling diodes
• DC-DC converters
• Lighting systems

Technical Specifications

With a repetitive peak reverse voltage (Vrrm) of 600V and a continuous forward current (If) of 1A, the MURA160T3G is capable of handling typical circuit demands with ease. Its operating junction temperature range from -55°C to +150°C ensures stability and reliability across a wide range of environmental conditions.

In summary, the MURA160T3G Ultrafast Rectifier from ON Semiconductor is a robust, efficient, and versatile component ideal for high-speed switching applications where performance and reliability are critical. Its compact footprint and compliance with environmental standards make it a preferred choice for modern electronic designs.
