Products specifications

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Cut Tape (CT)
Status Obsolete
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 100V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Maximum) at If 790mV at 3A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage at Vr 50μA at 100V
Mounting Style SMD
Manufacturer Package DO-214AB, SMC
Supplier Device Package SMC
Operating Temperature - Junction -65°C ~ 175°C
Family Part Number MBRS3100
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1216509-MBRS3100T3
Manufacturer Homepage www.onsemi.com
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Safety
Ultra Librarian 3D Model Ultra Librarian MBRS3100T3 CAD Model

Description

The MBRS3100T3 from ON Semiconductor is a high-performance Schottky barrier rectifier designed for applications requiring low voltage drop and high efficiency. This rectifier is a popular choice for power supply designs, offering a forward current of 3A with a low forward voltage drop, ensuring minimal power loss during operation.

Key Features

  • High Surge Capacity: The MBRS3100T3 is capable of handling high surge currents, making it suitable for applications prone to surges and spikes.
  • Low Power Loss: With its Schottky barrier design, this rectifier has a low forward voltage drop, reducing power loss and improving efficiency.
  • High Current Capability: The device supports a forward current of 3A, accommodating the needs of high current applications.
  • Temperature Range: This component operates within a junction temperature range of -55°C to +150°C, making it reliable in various environmental conditions.

Applications

The MBRS3100T3 is versatile and can be used in a variety of applications, including:

  • Switching power supplies
  • Converters
  • Free-wheeling diodes
  • Reverse battery protection
  • Automotive applications

Package and Quality

ON Semiconductor's MBRS3100T3 comes in a compact SMB package, which is ideal for space-constrained applications. The product adheres to strict quality standards, ensuring reliability and performance consistency.

Environmental Compliance

Committed to environmental sustainability, ON Semiconductor ensures that the MBRS3100T3 complies with RoHS directives, making it a lead-free and environmentally friendly choice for electronics designers and manufacturers.

Conclusion

In summary, the MBRS3100T3 Schottky barrier rectifier from ON Semiconductor is a robust and efficient solution for a wide range of power rectification needs. With its high surge capacity, low power loss, and high current capability, it stands out as a reliable component for your power management requirements.
