Products specifications

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 550mV @ 1A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 500μA @ 40V
Mounting SMD (SMT)
Case / Package SOD-123L
Operating Temperature - Junction -55°C to 125°C
Win Source Part Number 074274-MBR140SFT1G
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Portable Devices, Communications & Networking, Consumer Electronics, Computers & Computer Peripherals, Automotive
Family Name MBR140SF
Introduction Date October 09, 2002
ECCN EAR99
Country of Origin Malaysia, United States of America
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian MBR140SFT1G CAD Model

Description

ON Semiconductor MBR140SFT1G Schottky Power Rectifier

The MBR140SFT1G from ON Semiconductor is a state-of-the-art Schottky barrier rectifier designed for high-efficiency power management applications. This compact surface mount device is characterized by its low forward voltage drop and high surge handling capability, making it a suitable choice for a wide range of electronic circuits, including power supply, DC-DC converters, and reverse battery protection.

Key Features

  • Low Forward Voltage Drop: The device offers a low forward voltage drop, which enhances system efficiency by reducing power loss during operation.
  • High Surge Capability: With its excellent surge handling capacity, the MBR140SFT1G can withstand high current spikes, ensuring reliability in demanding situations.
  • Power Dissipation: Rated at a power dissipation of 500 mW, this Schottky rectifier can handle moderate power levels, suitable for a variety of applications.
  • Low Power Loss: The low power loss characteristics of this component contribute to the overall energy efficiency of the system in which it is used.
  • Guard Ring Die Construction: The guard ring construction provides enhanced reliability and stability by protecting against potential breakdown due to high voltage stress.
  • Temperature Range: It operates within a junction temperature range of -55°C to +150°C, accommodating a wide spectrum of environmental conditions.

Applications

  • Switching power supplies
  • Converters
  • Free-wheeling diodes
  • Reverse battery protection
  • Automotive applications
  • Portable devices

The MBR140SFT1G is provided in a compact SOD-123FL package, which is optimized for automated assembly processes and takes up minimal space on a printed circuit board. Its Pb-free design also meets environmental standards, such as RoHS compliance, ensuring that it is suitable for use in green products. With its combination of efficiency, reliability, and compact form factor, the MBR140SFT1G Schottky barrier rectifier from ON Semiconductor is an excellent choice for designers looking to enhance the performance of their power management systems.
