Products specifications

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 450mV @ 700mA
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 60μA @ 30V
Mounting SMD (SMT)
Case / Package SOD-123
Operating Temperature - Junction -65°C to 125°C
Win Source Part Number 126579-MBR130T3G
Ultra Librarian 3D Model Ultra Librarian MBR130T3G CAD Model

Description

The MBR130T3G from ON Semiconductor is a high-performance Schottky Barrier Rectifier designed for applications requiring low voltage drop and high efficiency. This rectifier is particularly suitable for use in switching power supplies, converters, free-wheeling diodes, and reverse battery protection.

Key Features

  • Voltage Rating: The MBR130T3G has a maximum repetitive peak reverse voltage (VRRM) of 30V, making it ideal for a wide range of low voltage applications.
  • Current Capacity: It can handle an average rectified forward current (IF(AV)) of 1A, ensuring reliable performance in moderate power scenarios.
  • Low Forward Voltage Drop: With a low forward voltage drop, this device ensures minimal power loss and higher efficiency, which is critical in power-sensitive designs.
  • Fast Switching Speed: The fast switching capability of the MBR130T3G provides improved performance in high-frequency applications.
  • Thermal Performance: The device is capable of operating within a junction temperature range of -65°C to 125°C, making it suitable for use in challenging thermal environments.

Package and Compliance

The MBR130T3G comes in a compact surface-mount SMB (DO-214AA) package, which allows for efficient use of PCB space. It is compliant with RoHS and Halogen-Free standards, ensuring environmental safety and suitability for use in green products.

Applications

With its robust features, the MBR130T3G is an excellent choice for a variety of applications, including:

  • Switching power supplies
  • DC-DC converters
  • Polarity protection devices
  • Power management in portable and battery-powered devices
  • Automotive applications

Conclusion

The MBR130T3G Schottky Barrier Rectifier by ON Semiconductor is a versatile and reliable component that offers designers a balanced performance of low power loss and high efficiency. Its suitability for a wide range of applications makes it a go-to choice for engineers looking to optimize their power management systems.
