Manufacturer ON Semiconductor
Packaging Reel
FET Type P-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 150V
Current - Continuous Drain (Id) at 25°C 2A , 8.4A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 6V, 10V
Rds On (Maximum) at Id, Vgs 307mOhm at 2A, 10V
Vgs(th) (Maximum) at Id 4V at 250μA
Gate Charge (Qg) (Maximum) at Vgs 13nC at 10V
Maximum Vgs ±25V
Input Capacitance (Ciss) (Maximum) at Vds 885pF at 75V
Power Dissipation (Maximum) 2.3W , 40W (Tc)
Temperature Range - Operating -55°C ~ 150°C
Mounting Style SMD
Supplier Device Package 8-MLP (3.3x3.3)
Manufacturer Package 8-PowerWDFN
Manufacturer Pack Quantity 3,000
MSL Level 1 (Unlimited)
Popularity High
Supply and Demand Status Sufficient
Win Source Part Number 801698-FDMC86262P
Ultra Librarian 3D Model Ultra Librarian FDMC86262P CAD Model

Description

Introducing the FDMC86262P PowerTrench® MOSFET from ON Semiconductor

ON Semiconductor's FDMC86262P is a cutting-edge PowerTrench® MOSFET designed to deliver high efficiency and power density for a wide range of applications. This advanced semiconductor device is a testament to ON Semiconductor's commitment to providing innovative solutions that meet the evolving needs of modern electronics.

Key Features

  • Low R<sub>DS(on): The FDMC86262P boasts an exceptionally low on-resistance, which translates to reduced conduction losses and improved overall efficiency.
  • High Power Density: With its compact 3.3mm x 3.3mm footprint, this MOSFET is ideal for space-constrained applications, offering a high power density without compromising on performance.
  • PowerTrench® Technology: ON Semiconductor's proprietary PowerTrench® process enhances the device's switching performance, minimizing switching losses and further improving efficiency.
  • Optimized Gate Charge: The FDMC86262P features an optimized gate charge, which reduces the power required to drive the MOSFET, leading to lower switching losses and better high-frequency operation.

Applications

The FDMC86262P is versatile and can be used in a variety of applications, including:

  • DC-DC converters
  • Power supply modules
  • Motor drives
  • Battery management systems
  • Load switches

Performance and Reliability

ON Semiconductor has engineered the FDMC86262P to perform reliably in demanding conditions. It operates over a wide temperature range and is designed to withstand the rigors of high-performance applications. The device also features robust thermal characteristics, ensuring stable operation even under high current loads.

Environmental Considerations

As part of ON Semiconductor's commitment to environmental stewardship, the FDMC86262P is RoHS compliant, ensuring it meets the latest environmental standards and regulations. This MOSFET is designed not only for performance but also to minimize its ecological footprint.

Overall, the FDMC86262P from ON Semiconductor exemplifies the company's dedication to providing high-quality, efficient, and reliable semiconductor solutions. Its combination of low R<sub>DS(on), high power density, and PowerTrench® technology makes it an excellent choice for designers looking to optimize their power management systems.
