Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Tube
Status Obsolete
Transistor Polarity N-Channel
Technology MOSFET
Vds - Drain-Source Breakdown Voltage 900V
Id - Continuous Drain Current 9A
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Maximum) at Id, Vgs 1.4Ohm at 4.5A, 10V
Gate Source Voltage(th) (Maximum) at Id 5V at 250μA
Gate Charge (Qg) (Maximum) at Vgs 58nC at 10V
Gate Source Voltage (Maximum) ±30V
Input Capacitance (Ciss) (Maximum) at Vds 2730pF at 25V
Power Dissipation (Maximum) 280W
Temperature Range - Operating -55°C ~ 150°C
Mounting Style Through Hole
Supplier Device Package TO-3P
Manufacturer Package TO-3P-3, SC-65-3
Manufacturer Pack Quantity 450
MSL Level 1 (Unlimited)
Win Source Part Number 1175177-FQA9N90C
Manufacturer Homepage www.fairchildsemi.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name FQA9N90C
Introduction Date March 05, 2003
ECCN EAR99
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian FQA9N90C CAD Model

Description

The ON Semiconductor FQA9N90C is a high-performance N-Channel QFET® MOSFET designed to deliver robust performance for a wide range of applications. This power MOSFET is engineered to provide efficient power management and high-speed switching with low on-resistance and a high blocking voltage.

Key Features:

  • High Voltage Capability: With a drain-source voltage (V<sub>DS) of 900V, the FQA9N90C is suitable for high voltage applications, providing excellent power handling capabilities.
  • Low On-Resistance: A low R<sub>DS(on) of 1.5 Ohms minimizes conduction losses, enhancing overall efficiency and thermal performance.
  • High Current Rating: The device can handle continuous drain currents (I<sub>D) up to 9A, making it ideal for handling high current loads.
  • Fast Switching Speed: The FQA9N90C offers fast switching with a low gate charge (Q<sub>g), reducing switching losses and improving performance in high-frequency applications.
  • Robust Thermal Performance: The device is encapsulated in a TO-3PN package, which provides excellent heat dissipation and robustness for demanding environments.

Applications:

The versatility of the FQA9N90C MOSFET makes it suitable for a variety of applications, including:

  • Power supplies and DC-DC converters
  • Motor drives and inverters
  • Lighting systems, such as HID and LED lighting
  • Switch Mode Power Supplies (SMPS)
  • High voltage switching applications

Reliability:

ON Semiconductor's commitment to quality ensures that the FQA9N90C MOSFET meets stringent reliability standards. It is designed for long-term stability and performance, even under challenging conditions.

Environmental Considerations:

The FQA9N90C is RoHS compliant, reflecting ON Semiconductor's dedication to environmental responsibility by reducing the use of hazardous substances in its products.
