The TJA1043T,118 is a high-speed Controller Area Network (CAN) transceiver from NXP Semiconductors designed to provide an interface between a CAN protocol controller and the physical two-wire CAN bus. It is tailored for use in automotive applications and industrial automation systems where reliable data communication is essential.

Key Features

• ISO 11898-2:2016 Compliant: The device meets the specifications of the ISO standard for high-speed CAN transceivers, ensuring compatibility with other compliant devices in the network.
• Low Power Management: The TJA1043T,118 features several power-saving modes, including a Silent mode and Standby mode, which help reduce the overall power consumption of the system.
• Bus Fault Protection: Enhanced bus fault protection of up to ±58 V against transients and short circuits ensures robust performance and reliability in harsh environments.
• High Electromagnetic Compatibility (EMC): The transceiver offers excellent EMC performance, minimizing electromagnetic emissions and providing high immunity against interference.
• High ESD Protection: Integrated Electrostatic Discharge (ESD) protection circuits safeguard the transceiver against electrostatic discharges, enhancing system durability.

Applications

The versatility of the TJA1043T,118 makes it suitable for a wide range of applications, particularly where high-speed data communication and robustness are required. Typical applications include:

• Automotive networks such as powertrain, chassis, and body control
• Industrial control systems and robotics
• Medical equipment data buses
• Marine electronics and avionics communication systems

Technical Specifications

The TJA1043T,118 operates at a nominal supply voltage of 5V, with a bus speed of up to 1 Mbit/s. The package type is SOIC-14, which is suitable for surface-mount technology (SMT), and it operates over a temperature range of -40°C to +125°C, making it reliable in extreme conditions.

Ordering Information

The product is available with the orderable part number TJA1043T,118. For detailed ordering and product information, customers should consult the datasheet or contact NXP Semiconductors directly.
