Products specifications Report Issue?

Category RF/IF and RFID>RF Misc ICs and Modules
Mfr NXP USA Inc.
Package Tape & Reel
Function FM IF System
RF Type Cellular, ASK, FSK
Secondary Attributes RSSI Equipped
Mounting SMD (SMT)
Package / Case 16-XFQFN Exposed Pad
Supplier Device Package 16-HXQFN (3x3)
Base Product Number SA614
Other Names 568-11492-1,568-11492-2,935302563115,568-11492-6
Standard Package 1,500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1236128-SA614AHRX
Ultra Librarian 3D Model Ultra Librarian SA614AHRX CAD Model

Description

NXP SA614AHRX Low Power FM IF System

The NXP SA614AHRX is a monolithic integrated low-power FM IF system incorporating high-performance mixer, oscillator, limiting amplifier, and signal strength indicator functionalities. This versatile component is designed for high sensitivity applications and is an ideal choice for use in wireless communication systems.

Key Features:

  • High Sensitivity: The SA614AHRX boasts an exceptional sensitivity level, making it suitable for demanding environments where signal strength can be weak.
  • Low Power Consumption: With its focus on low power usage, this IF system is optimized for battery-operated devices, ensuring longer operational life without sacrificing performance.
  • Integrated Mixer and Oscillator: The on-chip mixer and oscillator reduce the need for external components, simplifying the design and reducing the overall system cost.
  • Limiting Amplifier: The built-in limiting amplifier offers a wide dynamic range, which is critical for consistent performance across varying signal conditions.
  • Signal Strength Indicator: The integrated signal strength indicator provides immediate feedback on the incoming signal's quality, which is essential for adaptive systems.

Applications:

The SA614AHRX is designed for a variety of applications, including:

  • Cellular telephones
  • Wireless communication devices
  • PCS systems
  • Radio and TV tuners
  • Portable communication equipment

Technical Specifications:

Some of the technical specifications of the SA614AHRX include:

  • Supply Voltage Range: 2.7V to 5.5V
  • Operating Temperature: -40°C to +85°C
  • Package: SO16

Overall, the NXP SA614AHRX is a highly integrated, efficient, and reliable solution for FM IF systems that require high sensitivity and low power consumption. Its combination of features makes it a popular choice for designers looking to create compact and energy-efficient wireless communication devices.
