The MPX2100D is a highly accurate and reliable pressure sensor from NXP Semiconductors, designed for a wide range of applications. This integrated silicon pressure sensor is based on NXP's advanced piezoresistive transducer technology, which provides an analog output voltage that is directly proportional to the applied pressure.
Key Features
- Pressure Range: The MPX2100D is designed to measure absolute pressure in the range of 0 to 100 kPa (0 to 14.5 psi).
- Sensitivity: It offers a high sensitivity of 40 mV/kPa, ensuring precise measurements for critical applications.
- Accuracy: The device boasts a small total error band, which guarantees accurate pressure readings over a wide temperature range.
- Temperature Compensated: The MPX2100D includes temperature compensation from -40°C to +125°C, making it suitable for various environmental conditions.
- Stable Output: The sensor maintains a stable output over its lifetime, thanks to the robust design and manufacturing process.
Applications
The versatile nature of the MPX2100D makes it ideal for a range of applications, including but not limited to:
- Process control systems
- Medical devices
- Pneumatic control systems
- Hydraulic systems
- Air compressor control
Technical Specifications
Parameter
Value
Operating Pressure Range
0 to 100 kPa
Sensitivity
40 mV/kPa
Supply Voltage
10 VDC
Operating Temperature
-40°C to +125°C
Package
Unibody 4-pin
The MPX2100D is a testament to NXP's commitment to providing high-performance, reliable sensor solutions. Its robust design and precision make it an excellent choice for professionals seeking a dependable pressure sensor.
