Products specifications Report Issue?

Category Integrated Circuits (ICs)>PMIC - Power Distribution Switches, Load Drivers
Mfr NXP USA Inc.
Package Tape & Reel (TR)
Product Status Obsolete
Switch Type General Purpose
Number of Outputs 2
Output Configuration High Side
Output Type N-Channel
Interface SPI
Voltage - Load 8V ~ 36V
Supply Voltage - Operating 3V ~ 5.5V
Current - Output (Max) 3A
Rds On (Typ) 16mOhm (Max)
Features Internal PWM, Slew Rate Controlled, Watchdog Timer
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Temperature Range - Operating -40°C ~ 150°C (TJ)
Mounting SMD (SMT)
Supplier Device Package 23-PQFN (12x12)
Package / Case 23-PowerQFN
Base Product Number MC16
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names 934070599578
Standard Package 1,200
Win Source Part Number 990639-MC16XSD200FKR2
Ultra Librarian 3D Model Ultra Librarian MC16XSD200FKR2 CAD Model

Description

The MC16XSD200FKR2 is a state-of-the-art dual high-side switch manufactured by NXP Semiconductors, a leader in automotive and secure connectivity solutions. This advanced product is designed to deliver efficient and reliable control for a wide range of applications, including automotive, industrial, and smart control systems.

Key Features

  • High-Side Switch: The MC16XSD200FKR2 features two independent high-side switches, offering precise control for high-power loads with minimal power loss.
  • Advanced Power Management: Integrated with NXP's SMARTMOS technology, the device ensures robust power management capabilities, enhancing system reliability and performance.
  • High Current Capability: Capable of handling continuous current up to 20A per channel, this product is well-suited for driving high-current loads.
  • Protection Features: The device includes overcurrent, overtemperature, and short-circuit protection, safeguarding the system against potential damage.
  • Diagnostic Functions: Built-in diagnostic features provide real-time feedback on the status of the switches, aiding in system monitoring and fault detection.
  • Low Standby Current: The MC16XSD200FKR2 is designed for energy efficiency, with a low standby current that helps reduce overall power consumption.

Applications

The versatility of the MC16XSD200FKR2 makes it an ideal choice for a broad spectrum of applications. It's particularly well-suited for automotive environments where high-side switching is necessary for body control modules, power distribution boxes, and lighting systems. In industrial settings, it can be used for actuator control and power distribution tasks. Additionally, its robust design and diagnostic capabilities make it a reliable component for smart control systems that require consistent performance and system integrity.

Technical Specifications

  • Voltage Range: The device operates over a wide voltage range, accommodating various system requirements.
  • Package: The MC16XSD200FKR2 comes in a compact and thermally efficient package, enabling easy integration into space-constrained designs.
  • Quality and Reliability: NXP's commitment to quality ensures that the MC16XSD200FKR2 meets stringent industry standards for reliability and performance.

In conclusion, the MC16XSD200FKR2 from NXP is a powerful and reliable dual high-side switch that offers advanced features and protection mechanisms, making it a top choice for engineers and designers looking for a high-performance power management solution.
