Products specifications Report Issue?

Reference Date Code 15+
Reference case QFN
Manufacturer NXP
Manufacturer Homepage www.nxp.com
Win Source Part Number 717296-74AVC4T245GU
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name 74AVC4T245
Introduction Date July 06, 2009
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian 74AVC4T245GU CAD Model

Description

NXP 74AVC4T245GU: 4-bit Dual-Supply Translating Transceiver

The NXP 74AVC4T245GU is a 4-bit, dual-supply translating transceiver designed for asynchronous communication between data buses. This high-performance, low-power device facilitates voltage level translation between different logic levels ranging from 1.2V to 3.6V, making it an ideal component for multi-voltage digital systems.

Key Features:

  • Bi-directional Interface: With its 4-bit bi-directional data flow, this transceiver allows data transmission in both directions, from A to B or B to A, depending on the logic level at the direction control (DIR) input.
  • Dual-Supply Voltage: The device operates with two independent power supply voltages, V<sub>CCA and V<sub>CCB, which can range from 1.2V to 3.6V, providing the flexibility to interface between different logic levels without the need for external level shifters.
  • High-Speed Operation: The 74AVC4T245GU is designed for high-speed operation, supporting data transfer rates that are suitable for the demands of modern digital systems.
  • Low Power Consumption: This transceiver has been optimized for low power consumption, which is critical for battery-powered and energy-efficient applications.
  • Bus Hold Function: The device includes a bus hold feature that prevents floating inputs, thereby ensuring stable operation without the need for external pull-up or pull-down resistors.

Applications:

The versatility of the NXP 74AVC4T245GU makes it suitable for a wide range of applications, including:

  • Mobile and portable devices
  • Data communication systems
  • Multi-voltage system level translation
  • Microprocessor or microcontroller interfacing
  • Server and networking equipment

Package Information:

The 74AVC4T245GU is available in a space-saving 16-pin TSSOP package, which is ideal for applications where board space is at a premium. The package is RoHS compliant and designed for surface mount technology (SMT), allowing for efficient assembly in high-volume production environments.

With its combination of dual-supply voltage capability, high-speed operation, and low power consumption, the NXP 74AVC4T245GU is a robust solution for modern electronics requiring reliable logic level translation.
