Product Overview: 74AHCT259PW,118

The 74AHCT259PW,118 is a high-speed Si-gate CMOS device from NXP Semiconductors, renowned for its robust performance and versatility. This particular integrated circuit is designed to be used in a wide range of applications, including industrial, communication, and computing environments where reliable logic operations are critical. The 74AHCT259PW,118 is an 8-bit addressable latch that operates as a memory-mapping device with a common data input and output.

Key Features

• Logic Type: Addressable Latch
• Number of Bits per Element: 8-Bit
• Output Type: 3-State
• Supply Voltage Range: 4.5V to 5.5V
• Operating Temperature Range: -40°C to +125°C
• Package Type: TSSOP
• Pin Count: 16
• Logic Family: AHCT
• Propagation Delay Time: 12ns at 5V

Functional Description

The 74AHCT259PW,118 has a flexible structure that includes eight latches with three-state outputs for bus-oriented applications. Each latch is addressable through a common input, which allows the device to be used in a variety of memory-related functions. The device can also operate as a single 8-output demultiplexer with a common data input. It features an active low latch enable (LE) input and an active low output enable (OE) input, which provide control over the input and output of data, respectively.

Applications

Due to its high-speed nature and versatility, the 74AHCT259PW,118 is suitable for various applications such as:

• Memory address decoding
• Data routing
• Control logic
• Input/output port expansion

Quality and Reliability

NXP Semiconductors ensures that the 74AHCT259PW,118 meets the highest quality and reliability standards. The device is subjected to rigorous testing and verification processes, making it a reliable choice for critical and high-performance applications.
