Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Purpose Standard
Type D-Type
Output Type Non-Inverted
Number of Elements 1
Number of Bits per Element 8
Max Frequency 120MHz
Max Propagation Delay @ V, Max CL 10.5ns @ 5V, 50pF
Trigger Type Positive Edge
Current - Output High, Low 8mA, 8mA
Supply Voltage - Operating 2 V to 5.5 V
Current - Quiescent 4μA
Input Capacitance 3pF
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Dimension 20-TSSOP (0.173", 4.40mm Width)
Win Source Part Number 25553-74AHC377PW
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 74AHC377PW CAD Model

Description

Product Overview: 74AHC377PW by NXP

The 74AHC377PW is a high-speed, advanced CMOS device manufactured by NXP Semiconductors. It is designed to provide optimal performance in a wide range of applications that require edge-triggered registers. The 74AHC377PW is a part of the 74AHC family, which is well-known for its low power consumption and high noise immunity, making it suitable for interfacing with high-speed logic systems.

Key Features

  • Octal D-type Flip-Flop: The 74AHC377PW features eight edge-triggered D-type flip-flops with individual D inputs and O outputs.
  • Positive-Edge Triggering: The flip-flops are triggered on the positive-going transition of the clock input, ensuring reliable operation and synchronization with system clocks.
  • Enable Input: The device includes an enable input (OE) which, when LOW, allows data on the D inputs to be transferred to the O outputs on the next positive edge of the clock.
  • Wide Operating Voltage: It operates over a broad voltage range from 2.0V to 5.5V, catering to various logic levels and making it versatile for mixed-voltage applications.
  • High-Speed Performance: The 74AHC377PW is characterized for operation from -40°C to +125°C, with a high-speed performance that meets the needs of fast-paced digital systems.
  • Low Power Dissipation: The device boasts low power dissipation, which is a crucial attribute for energy-sensitive designs.
  • Surface-Mount Package: It comes in a TSSOP20 package, which is ideal for space-constrained applications requiring surface-mount technology.
  • ESD Protection: High electrostatic discharge (ESD) protection levels are provided to prevent damage from static electricity and handling.

Applications

The 74AHC377PW is suitable for a variety of applications, including:

  • Buffer/Storage Registers
  • Shift Registers
  • Pattern Generators
  • Data Storage and Transfer Systems
  • Microprocessor Support Circuits

With its robust design and advanced features, the 74AHC377PW from NXP provides a reliable solution for designers looking to implement high-speed, low-power flip-flops in their digital systems.
