Product 78615/2JC from Murata Power Solutions Inc. is a 500µH general purpose pulse transformer with a 1CT:1CT turns ratio. It is surface mount and has a size of 0.375" L x 0.354" W (9.52mm x 9.00mm) with a height of 0.250" (6.35mm). It has an operating temperature range of 0°C ~ 70°C.

Pulse transformers are used to isolate and transfer electrical signals between two circuits. They are typically used in power supplies, telecommunications equipment, and industrial control systems.

The 78615/2JC pulse transformer is ideal for a wide range of applications, including:

• Power supplies
• Telecommunications equipment
• Industrial control systems
• Test and measurement equipment
• Medical devices
• Consumer electronics

Some of the key features of the 78615/2JC pulse transformer include:

• High efficiency
• Low distortion
• Wide frequency response
• Excellent isolation
• RoHS compliant

The 78615/2JC pulse transformer is a reliable and high-performance component that is ideal for a wide range of applications. It is available from a variety of distributors, including Digi-Key Electronics.

Here are some additional details about the 78615/2JC pulse transformer:

• Inductance: 500µH
• Turns ratio: 1CT:1CT
• Isolation voltage: 1000Vrms
• Leakage inductance: 10µH
• Distributed capacitance: 10pF
• Operating temperature range: 0°C ~ 70°C

The 78615/2JC pulse transformer is a valuable component for any engineer or hobbyist working with electronic circuits. It is a reliable and high-performance component that can be used in a wide range of applications.
