Same model may have multiple batches, images only for reference.
83424-9014 Real Image
Same model may have multiple batches, images only for reference.

83424-9014

Part No 83424-9014
Manufacturer Molex, LLC
Catalog Circular Connectors
Description 1.27mm Pitch Commercial Micro D, Cable Receptacle Kit, 25 Circuits
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Contact Plating Gold
Country of Origin US
Current Rating 1 A
ELV Compliant
Gender Receptacle
Insulation Resistance 5 GΩ
Lead Pitch 1.27 mm
Length 30.1 mm
Max Operating Temperature 70 °C
Min Operating Temperature -55 °C
Number of Circuits 25
Number of Conductors 25
Number of Contacts 25
Number of Positions 25
Number of Rows 2
Packaging Bulk
REACH SVHC No SVHC
RoHS Compliant
Shielding Shielded
Voltage Rating (AC) 350 V
Win Source Part Number 1164114-83424-9014
Categories Circular Connectors
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 83424-9014 CAD Model

Description

This circular connector is a compliant RoHS product manufactured by Molex, LLC.

  • Win Source Part Number: 1164114-83424-9014
  • RoHS Regulations: compliant
  • Temperature Range: -55 °C to 70 °C
