Same model may have multiple batches, images only for reference.
501646-1000 Real Image
Same model may have multiple batches, images only for reference.

501646-1000

Part No 501646-1000
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description 2.00mm Pitch, iGrid Receptacle Crimp Housing, Dual Row, Positive Lock, 10 Circuits, Natural
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Natural
Connector Type Receptacle, Socket
Contact Gender Female
Country of Origin US
Current Rating 2 A
Depth 11.05 mm
Fastening Type Latch
Gender Receptacle
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Housing Color Natural
Housing Material Nylon
Length 12 mm
Max Operating Temperature 85 °C
Min Operating Temperature -40 °C
Mount Cable, Free Hanging
Number of Circuits 40
Number of Contacts 10
Number of Positions 10
Number of Rows 2
Orientation Vertical
Pitch 2 mm
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Row Spacing 2.0066 mm
Schedule B 8536695050, 8536695050
Termination Crimp
Wire/Cable Gauge 28 AWG
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 22 AWG
Win Source Part Number 1184650-501646-1000
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 501646-1000 CAD Model

Description

The Molex 1184650-501646-1000 is a 2mm pitch, 10 contacts, vertical receptacle socket connector.

  • Pitch: 2mm
  • Contacts: 10
  • Mounting Type: Vertical
  • Current Rating: 2A
  • Voltage Rating: 125V
  • Contact Material: Copper Alloy with Gold Plating
  • Housing Material: Nylon with Natural Color
  • Category: Circular Connectors - Housings
  • RoHS Compliant: Yes
  • Flammability Rating: UL94 V-0
  • Mount: Cable, Free Hanging
  • Wire Gauge: 22-28 AWG
