Same model may have multiple batches, images only for reference.
22287112 Real Image
Same model may have multiple batches, images only for reference.

22287112

Part No 22287112
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Header Connector, pcb Mount, recept, 11 Contacts, pin, 0.1 Pitch, pc Tail W/retnn Terminal
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Material Brass
Contact Mating Length 9.1694 mm
Contact Plating Gold
Contact Resistance 20 mΩ
Country of Origin US
Current Rating 4 A
Depth 10.41 mm
Gender Male
Housing Color Black
Housing Material Nylon
Length 27.94 mm
Material Brass
Max Operating Temperature 75 °C
Min Operating Temperature 0 °C
Mount Through Hole
Number of Circuits 11
Number of Contacts 11
Number of Positions 11
Number of Rows 1
Orientation Right Angle
Packaging Bulk
Pitch 2.54 mm
Plating Tin
RoHS Compliant
Termination Solder
Win Source Part Number 1134652-22287112
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 22287112 CAD Model

Description

The Molex 1134652-22287112 is a circular connector housing with a male pin connector type.

  • Connector Type: Male Pin
  • Positions: 11
  • Pitch: 2.54 mm
  • Color: Black
  • Termination: Solder
  • Contact Plating: Gold
  • Orientation: Right Angle
  • RoHS: Compliant
  • Manufacturer: Molex
