Part No 0010894202
Manufacturer Molex, LLC
Catalog Rectangular Connectors
Description CONN HEADER R/A 20POS 2.54MM / Connector Header Through Hole, Right Angle 20 position 0.100" (2.54mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors>Headers, Male Pins
Manufacturer Molex
Packaging Tube
Connector Type Header, Breakaway
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 20
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Unshrouded
Mounting Through Hole, Right Angle
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.240" (6.10mm)
Contact Length - Post 0.110" (2.79mm)
Insulation Height 0.220" (5.60mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 15.0µin (0.38µm)
Contact Finish - Post Tin
Contact Material Copper Alloy
Insulation Material Polyester, Glass Filled
Material Flammability Rating UL94 V-0
Insulation Color Black
Contact Finish Thickness - Post 74.8µin (1.90µm)
Applications Automotive, General Purpose, Lighting, Medical, Telecommunications
Base Product Number 001089
RoHS Status ROHS3 Compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Part Number 10-89-4202,WM23742,10-89-4202-ND,70216-0243,10894202
Standard Package 1
Win Source Part Number 1332450-0010894202
Ultra Librarian 3D Model Ultra Librarian 0010894202 CAD Model

Description

The Molex 1332450-0010894202 is a 20-position header, breakaway connector with a pitch of 0.100" (2.54mm).

  • Manufacturer: Molex
  • Positions: 20
  • Type: Header, Breakaway
  • Pitch: 0.100" (2.54mm)
  • Mounting: Through-Hole
  • Configuration: Right-Angle
  • Contact Finish: Gold
  • Contact Finish Thickness: 15.0µin (0.38µm)
  • Post Contact Finish: Tin
  • Post Contact Finish Thickness: 74.8µin (1.90µm)
  • REACH: Unaffected
  • HTSUS: 8536.69.4040
  • Standard Package: 1
