Products specifications Report Issue?

Category Integrated Circuits (ICs)>Embedded>Microcontrollers
Manufacturer Microchip Technology
Packaging Tube
Core Processor PIC
Core Size 8-Bit
Speed 40MHz
Peripherals POR, WDT
Number of I/O 20
Program Memory Size 3KB (2K x 12)
Program Memory Type OTP
RAM Size 72 x 8
Voltage - Supply (Vcc/Vdd) 2.5V ~ 6.25V
Oscillator Type External
Temperature Range - Operating 0°C ~ 70°C
Mounting Through Hole
Case / Package 28-DIP (0.600", 15.24mm)
Supplier Device Package 28-PDIP
Base Product Number PIC16C57
RoHS Status ROHS3 Compliant
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.31.0001
Other Part Number PIC16C57-LP/P-NDR
Standard Package 15
Win Source Part Number 1322572-PIC16C57-LP/P
Ultra Librarian 3D Model Ultra Librarian PIC16C57-LP/P CAD Model

Description

Microchip Technology PIC16C57-LP/P Microcontroller

The PIC16C57-LP/P is a versatile 8-bit microcontroller from Microchip Technology, designed to offer a robust and cost-effective solution for a wide range of embedded applications. Known for its low-power consumption and high performance, this microcontroller is ideal for designers looking for a reliable and efficient microcomputing core.

At the heart of the PIC16C57-LP/P is a powerful RISC architecture that allows it to execute most instructions in a single cycle, thereby achieving exceptional speed. The device operates with a typical frequency of 4 MHz, providing a solid balance between speed and power usage, making it suitable for battery-powered or power-sensitive applications.

This microcontroller comes with 2KB of on-chip program memory, which is ample for simple to moderately complex tasks. Although it does not support an internal oscillator, it is flexible with external clock sources, giving designers the freedom to choose the appropriate clocking mechanism for their specific needs. The PIC16C57-LP/P also includes 72 bytes of data RAM, which is sufficient for handling temporary data and variables during operation.

The I/O capabilities of the PIC16C57-LP/P are noteworthy, featuring 20 general-purpose I/O pins that can be configured to handle various peripheral functions. This versatility makes it an excellent choice for interfacing with sensors, actuators, and other external devices. Additionally, the microcontroller supports a wide range of supply voltages from 2.5V to 5.5V, providing flexibility in different system voltage levels.

From a programming standpoint, the PIC16C57-LP/P is supported by Microchip's mature and user-friendly development tools, including the MPLAB IDE and a range of in-circuit emulators and programmers. This ensures that developers have access to a comprehensive ecosystem for coding, debugging, and testing their applications.

The PIC16C57-LP/P is available in a 28-pin PDIP package, which is easy to handle and integrate into various PCB designs. Its temperature range of -40°C to +85°C guarantees stable operation across diverse environmental conditions, making it suitable for industrial, automotive, and consumer electronics applications.

In summary, the PIC16C57-LP/P microcontroller from Microchip Technology is a reliable, efficient, and flexible solution for a multitude of embedded system designs, offering a perfect blend of power, performance, and peripheral integration.
