Products specifications Report Issue?

Category Circuit Protection>TVS - Diodes
Mfr Rohm Semiconductor
Series Automotive, AEC-Q101
Package Tape & Reel
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 20V
Voltage - Breakdown (Min) 22.2V
Voltage - Clamping (Max) @ Ipp 32.4V
Current - Peak Pulse (10/1000µs) 6.2A
Power - Peak Pulse 200W
Power Line Protection No
Applications Automotive
Temperature Range - Operating 150°C (TJ)
Mounting SMD (SMT)
Package / Case SOD-123F
Supplier Device Package PMDU
Base Product Number SMF20
Other Names SMF20VTFCT,SMF20VTFDKR
Standard Package 3,000
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 1298604-SMF20VTFTR
Ultra Librarian 3D Model Ultra Librarian SMF20VTFTR CAD Model

Description

This TVS diode is a zener type diode that comes under the category of circuit protection.

  • Series: automotive series
  • Certification: AEC-Q101 certified
  • Package: tape and reel
  • Standard Package: 3,000
  • Mounting Type: SMD (SMT)
  • Channel: unidirectional channel of 1
  • Voltage Rating: 20V
  • Voltage Breakdown: 22.2V
  • Voltage Clamping @ Ipp: 32.4V
  • Power Peak Pulse: 200W
  • Current Peak Pulse: 6.2A
  • Supplier Device Package: PMDU
  • Operating Temperature Range: 150°C (TJ)
