MCP1726EV

Part No MCP1726EV
Manufacturer Microchip Technology
Catalog Evaluation Boards - Linear Voltage Regulators
Description BOARD EVAL FOR MCP1726 / MCP1726 1 - Single Channels per IC Positive Adjustable Linear Voltage Regulator Evaluation Board
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Development Boards, Kits, Programmers>Evaluation Boards - Linear Voltage Regulators
Mfr Microchip Technology
Package Bulk
Channels per IC 1 - Single
Voltage - Output 0.8V ~ 5V
Current - Output 1A
Voltage - Input 2.3V ~ 6V
Regulator Type Positive Adjustable
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part MCP1726
Base Product Number MCP1726
RoHS Status RoHS non-compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8471.41.0150
Standard Package 1
Win Source Part Number 1078170-MCP1726EV
Ultra Librarian 3D Model Ultra Librarian MCP1726EV CAD Model

Description

Microchip Technology's MCP1726EV Product Overview

The MCP1726EV from Microchip Technology is a versatile and high-performance evaluation board designed for testing and prototyping with the MCP1726 series of voltage regulators. This product is a must-have for developers who need a reliable power management solution that can deliver up to 1A of output current while maintaining a low dropout voltage.

Key Features of MCP1726EV

  • High Current Output: The MCP1726EV is capable of delivering up to 1A of continuous current, making it suitable for a wide range of applications, including power-hungry devices.
  • Low Dropout Voltage: With a low dropout voltage, this evaluation board ensures efficient operation even when the input voltage is close to the output voltage, minimizing power loss and improving overall system efficiency.
  • Adjustable Output: The output voltage is adjustable, providing designers with flexibility to use the board in various applications requiring different voltage levels.
  • Thermal Overload Protection: The MCP1726EV includes thermal overload protection, which safeguards the device against damage from overheating.
  • Short-Circuit Protection: Built-in short-circuit protection enhances the safety and reliability of the board by preventing damage due to accidental shorts.
  • Stable Performance: The evaluation board is designed to maintain stability with ceramic output capacitors, ensuring consistent performance across different operating conditions.

Applications

The MCP1726EV is ideal for a variety of applications that require efficient power regulation, including but not limited to:

  • Battery-powered devices
  • Microcontroller power supplies
  • Portable electronics
  • Wireless communication devices
  • Smart home devices

Easy to Use and Integrate

The evaluation board comes with user-friendly features that simplify the prototyping process. It has test points for convenient measurement of input and output voltages, and the compact size of the board makes it easy to integrate into existing designs. For engineers and designers looking for a reliable and versatile voltage regulator solution, the MCP1726EV from Microchip Technology is an excellent choice.
