Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tray
Protocol Ethernet
Function Switch
Interface I2C, SPI
Standards 10/100 Base-T/TX PHY
Supply Voltage (V) 1.8V, 2.5V, 3.3V
Temperature Range - Operating -40°C ~ 85°C
Manufacturer Package 48-LQFP
Supplier Device Package 48-LQFP (7x7)
Family Part Number KSZ8863
Manufacturer Pack Quantity 250
MSL Level 3 (168 Hours)
Win Source Part Number 1193830-KSZ8863RLLI
Manufacturer Homepage www.micrel.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name KSZ8863R
Introduction Date July 01, 2009
ECCN 5A991.b
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian KSZ8863RLLI CAD Model

Description

Microchip Technology KSZ8863RLLI Product Overview

The Microchip Technology KSZ8863RLLI is a highly integrated 3-port switch on a chip, designed with a focus on performance, flexibility, and ease of use in various network applications. This robust networking solution is ideal for applications that require the efficient handling of Ethernet traffic across multiple ports.

Key Features:

  • Integrated Switching Core: The KSZ8863RLLI incorporates a high-performance non-blocking switch fabric that ensures seamless data transfer across its ports, with a 2-port switch and a single PHY for the third port.
  • Quality of Service (QoS): It supports QoS with four priority queues per port, providing prioritization of traffic and ensuring smooth operation for critical network services.
  • Energy Efficiency: Energy Efficient Ethernet (EEE) support helps in reducing power consumption during periods of low data activity, making it an environmentally friendly choice.
  • VLAN Support: The device includes VLAN (Virtual Local Area Network) capabilities, offering network segmentation and enhanced security.
  • Advanced Management: With features like IGMP snooping, MIB counters, and CPU control/data interfaces, the KSZ8863RLLI allows for sophisticated network management and monitoring.

Applications:

The KSZ8863RLLI is versatile and can be used in a range of networking environments, including:

  • Home networking equipment
  • Networked printers and multifunction devices
  • Industrial control and automation
  • Smart home and IoT devices
  • Set-top boxes and gaming consoles

Technical Specifications:

  • Package: 48-pin LQFP
  • Temperature Range: -40°C to +85°C
  • Supply Voltage: 1.8V to 3.3V
  • Standards Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.1p

The KSZ8863RLLI from Microchip Technology is a compact, feature-rich network switch solution that offers reliability and performance for a multitude of Ethernet-based applications. With its advanced features and capabilities, this product is designed to meet the growing demands of modern networked devices.
