Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Applications Ultrasound
Multiplexer/Demultiplexer Circuit 1:1
Switch Circuit SPST
Number of Channels 8
On-State Resistance (Max) 38Ohm
Voltage - Supply, Single (V+) 40V ~ 200V
Voltage - Supply, Dual (V±) ±40V ~ 160V
-3db Bandwidth 50MHz
Temperature Range - Operating 0°C ~ 70°C (TA)
Mounting Type Surface Mount
Case / Package 28-LCC (J-Lead)
Supplier Device Package 28-PLCC (11.5x11.5)
Package Tube
Supply and Demand Status Shortage
Win Source Part Number 1505676-HV232PJ-G
Ultra Librarian 3D Model Ultra Librarian HV232PJ-G CAD Model
