Microchip Technology's CD4741A is a precision Zener diode voltage reference in a small, two-pin DO-41 package. This component is designed to provide a highly stable and accurate reference voltage for various applications in the electronics industry. With a nominal voltage of 4.7V, it is ideal for use in power supplies, digital voltmeters, and other voltage regulation systems.

Key Features

• Stable Voltage Reference: The CD4741A offers a stable Zener voltage of 4.7V, making it suitable for precise voltage calibration and control.
• Low Dynamic Impedance: The dynamic impedance of this Zener diode is low, ensuring minimal voltage drop under varying load conditions and contributing to a stable voltage output.
• High Reliability: Manufactured by Microchip Technology, the CD4741A is built to high-quality standards, providing reliable performance over its lifespan.
• Wide Operating Current Range: This Zener diode operates efficiently across a broad range of currents, allowing for flexible integration into different circuit designs.
• DO-41 Package: The compact DO-41 package is suitable for through-hole mounting, making it easy to install on a variety of printed circuit boards.

Applications

The CD4741A from Microchip Technology is versatile and can be used in a wide array of applications, including:

• Power supply regulation
• Voltage monitoring
• Analog-to-digital converter reference
• Electronic calibration systems
• Automotive electronics

Specifications

For engineers and designers seeking a reliable voltage reference, the CD4741A from Microchip Technology offers the perfect blend of precision, stability, and ease of use, making it an excellent choice for your next project.
