The DS2480B+ is a sophisticated serial to 1-Wire line driver chip designed by Maxim Integrated, a renowned leader in the development of integrated circuits. This device is essential for systems where there is a need to convert standard serial communication signals to 1-Wire communication protocol signals, which is often used in applications requiring minimal wiring, such as in sensors and microcontroller interfaces.

Key Features

• Flexible Communication: The DS2480B+ supports flexible baud rates, allowing it to communicate with 1-Wire devices over a wide range of data speeds.
• Single Contact Interface: It provides a single contact serial interface to standard 1-Wire applications, simplifying the connection between microcontrollers and 1-Wire devices.
• Programmable Parameters: This device features programmable 1-Wire timing and slew rates to ensure optimal performance and compatibility with various 1-Wire devices.
• Low Power Consumption: Designed with power efficiency in mind, the DS2480B+ operates with a low power requirement, making it ideal for battery-powered applications.
• Robust Protection: It includes overvoltage protection on the 1-Wire line, ensuring a robust interface that can withstand harsh electrical environments.

Applications

The DS2480B+ is versatile and can be used in a wide array of applications. It is particularly useful in:

• Industrial control systems
• Environmental sensing and data logging
• Access control systems
• Networked devices for IoT applications

Technical Specifications

• Supply Voltage: 3.0V to 5.5V
• Operating Temperature Range: -40°C to +85°C
• Package Type: 8-pin SOIC
• Standard Compliance: Meets 1-Wire protocol standards

With the DS2480B+, Maxim Integrated continues its tradition of providing innovative solutions for complex communication requirements. This device is a testament to their commitment to quality and efficiency, offering a reliable and user-friendly interface for 1-Wire networks.
