Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Maxim Integrated
Part Status Obsolete(EOL)
Main Purpose Telecom, Line Interface Units (LIUs)
Utilized IC / Part DS21448
Supplied Contents Board(s)
Win Source Part Number 773202-DS21448DK
Popularity Medium
Supply and Demand Status Limited
Family Name DS21448
Introduction Date November 01, 2006
ECCN EAR99
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian DS21448DK CAD Model

Description

The DS21448DK from Maxim Integrated is a comprehensive evaluation kit designed for the DS21448 T1/E1/J1 single-chip transceiver. This evaluation kit provides designers with a robust platform for testing and prototyping telecommunications applications involving T1, E1, and J1 interfaces.

Key Features

  • Integrated Transceiver: The DS21448 integrates line interface, framer, and LIU for T1, E1, and J1 applications into a single chip, simplifying design and reducing board space requirements.
  • Flexible Configuration: The evaluation kit allows for easy configuration of the transceiver for different modes and features, enabling thorough testing for a variety of telecom scenarios.
  • Diagnostic Tools: Equipped with extensive diagnostic features, including jitter attenuation and generation, the kit is ideal for assessing the performance of communication systems.
  • User-Friendly Interface: The kit includes a graphical user interface (GUI) that simplifies the process of configuring and monitoring the transceiver's operation.
  • Comprehensive Documentation: Detailed documentation provides valuable insights into the DS21448's capabilities, facilitating a smooth evaluation and design process.

Applications

The DS21448DK is suited for a range of telecommunications applications, including:

  • Telecom Switching Systems
  • Channel Banks
  • Wireless Base Stations
  • Test Equipment
  • Integrated Access Devices

Package Contents

The evaluation kit includes:

  • DS21448 Evaluation Board
  • Power Supply
  • USB Cable for PC Interface
  • Software CD with GUI and Drivers
  • Comprehensive Evaluation Kit User Guide

With the DS21448DK, Maxim Integrated offers engineers a powerful tool for developing and testing T1/E1/J1 interface applications with efficiency and precision. The combination of a feature-rich transceiver chip and a user-friendly evaluation environment makes this kit an essential asset for telecommunications system development.
