The DS2118MB+T&R is a versatile and high-performance SCSI (Small Computer System Interface) terminator manufactured by Maxim Integrated, a leader in analog and mixed-signal engineering. This terminator is designed for use in a variety of SCSI applications, including servers, storage systems, and workstations, providing reliable termination for SCSI bus lines.

Key Features

• Integrated Termination: The DS2118MB+T&R contains precision-matched resistors that provide the correct termination for SCSI bus lines, ensuring signal integrity and minimizing reflections that can lead to data errors.
• Multi-Mode Compatibility: It supports Single-Ended (SE), High-Voltage Differential (HVD), and Low-Voltage Differential (LVD) SCSI modes, making it a versatile solution for various SCSI configurations.
• Automatic Mode Detection: The device automatically detects the SCSI mode and configures the termination accordingly, simplifying the design and reducing the need for manual intervention.
• Hot-Plugging Capability: The DS2118MB+T&R is designed to support hot swapping, allowing devices to be added or removed from the SCSI bus without the need to power down the system.
• Thermal Protection: Built-in thermal protection ensures the device operates within safe temperature ranges, preventing damage from overheating.
• Low Power Consumption: This terminator is designed for energy efficiency, which helps reduce the overall power consumption of the system it is used in.

Applications

The DS2118MB+T&R is suitable for a wide range of applications where reliable SCSI termination is required. It is commonly used in:

• RAID Systems
• Storage Area Networks (SAN)
• Server Attachments
• Workstation Attachments
• SCSI Expanders and Bridges

Package and Availability

The DS2118MB+T&R is offered in a compact 27-pin Mini-SO package, which is ideal for space-constrained applications. It is available in tape and reel (T&R) format, facilitating easy integration into automated manufacturing processes.

Maxim Integrated's commitment to quality and reliability ensures that the DS2118MB+T&R terminator meets the stringent requirements of high-performance SCSI systems, providing designers with a dependable solution for their data integrity needs.
