LTC2174IUKG-14#PBF - High-Performance ADC from Linear Technology

The LTC2174IUKG-14#PBF is a state-of-the-art analog-to-digital converter (ADC) developed by Linear Technology, which is now part of Analog Devices. This high-speed, low-power, 14-bit ADC is designed for applications that require high dynamic range and accuracy, such as medical imaging, communications, industrial instrumentation, and data acquisition systems.

Key Features:

• Resolution: 14-bit performance ensures precise digital representation of analog signals, enhancing the quality of the final output.
• Sampling Rate: With a maximum sampling rate of up to 125Msps (mega samples per second), it can handle high-speed signals and rapidly changing input conditions.
• Low Power Consumption: The device is optimized for low power operation, making it ideal for portable and battery-powered applications.
• Multiple Input Ranges: It supports various input ranges, providing flexibility in interfacing with different signal sources.
• Pin-Compatible Family: This ADC is part of a pin-compatible family, allowing for easy scalability and design flexibility.
• Integrated Features: It includes an internal reference and a fully differential sample-and-hold circuit, which simplifies the design and reduces external component count.

Robust Design:

The LTC2174IUKG-14#PBF operates over an industrial temperature range and comes in a robust, lead-free, 48-pin 7mm × 7mm QFN package, which is suitable for space-constrained applications. It also features enhanced ESD protection, ensuring reliability and longevity in harsh environments.

Applications:

This high-performance ADC is versatile and can be integrated into a wide array of applications:

• Medical Imaging Systems
• High-Speed Data Acquisition
• Wireless and Wired Communications
• Test and Measurement Equipment
• Industrial Control Systems

With its combination of speed, precision, and low power consumption, the LTC2174IUKG-14#PBF from Linear Technology is an excellent choice for designers looking to enhance the performance and efficiency of their systems.
