Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Linear Technology
Packaging Tube/Rail
Status Active
Voltage - Clamping 27V Adj
Technology External Switch
Number of Circuits 1
Applications Automotive
Mounting SMD (SMT)
Case / Package 12-DFN (4x3)
Voltage - Working 4 to 80V
Win Source Part Number 020430-LT4356HDE-1#PBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LT4356HDE-1#PBF CAD Model

Description

The LT4356HDE-1#PBF is a surge stopper device crafted by Linear Technology to provide robust protection to electronic systems against high voltage spikes, surges, and overcurrent events. This versatile component is designed to safeguard sensitive electronics in a variety of applications, ranging from automotive to industrial and avionics systems.

Key Features

  • Surge Protection: The LT4356HDE-1#PBF is capable of clamping input surges in excess of 100V to a safe level, ensuring the downstream electronics are protected from potentially damaging high voltage transients.
  • Overcurrent Protection: It includes an overcurrent protection feature that limits the output current during fault conditions, preventing thermal runaway and potential damage to the system.
  • Wide Operating Range: This device operates effectively with supply voltages ranging from 4V to 80V, making it suitable for a broad array of power systems.
  • Adjustable Output Clamp Voltage: Users can set the desired output clamp voltage using an external resistor divider, providing flexibility to match the protection level to the specific needs of the application.
  • Low Quiescent Current: The LT4356HDE-1#PBF maintains a low quiescent current, which is crucial for power-sensitive applications and extends the battery life in portable devices.

Applications

  • Automotive Electronics
  • Industrial Control Systems
  • Avionics and Marine Electronics
  • Telecommunications Infrastructure
  • Portable Devices with External Power

Package and Reliability

The LT4356HDE-1#PBF comes in a thermally enhanced 12-lead 4mm × 3mm DFN package, which ensures efficient heat dissipation for reliable operation even under high-power or high-temperature conditions. Linear Technology's commitment to quality means that this surge stopper is built to meet stringent industry standards for performance and durability.

Conclusion

With its combination of surge and overcurrent protection, wide operating range, and adjustable clamp voltage, the LT4356HDE-1#PBF is an ideal choice for designers looking to enhance the resilience and longevity of their electronic systems. Its compact package and low power consumption make it a versatile solution for protecting a wide range of electronic applications from harsh electrical environments.
