Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Connectors, Interconnects - Terminals - Solder Lug Connectors
Mfr Keystone Electronics
Package Bulk
Product Status Active
Terminal Type Standard
Style Smooth Edge
Hole Diameter 0.093" (2.36mm)
Mounting Type Flat
Length - Overall 0.515" (13.08mm)
Contact Material Brass
Contact Finish Tin
Standard Package 100 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.90.4000
Win Source Part Number 545838-4004
Ultra Librarian 3D Model Ultra Librarian 4004 CAD Model

Description

The 545838-4004 is a solder lug connector from Keystone Electronics.

  • Application: Terminal used in connectors and interconnects
  • Contact Finish: Tin
  • Contact Material: Brass
  • Overall Length: 0.515 inches (13.08mm)
  • Hole Diameter: 0.093 inches (2.36mm)
  • Mounting Type: Flat
  • Package: Bulk (100 pieces)
  • Edge Style: Smooth
  • Terminal Type: Standard
