Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Connectors, Interconnects - Terminals - Quick Connects, Quick Disconnect Connectors
Mfr Keystone Electronics
Package Bulk
Product Status Active
Terminal Type Standard
Gender Male
Tab Width 0.110" (2.79mm)
Tab Thickness 0.020" (0.51mm)
Termination Solder
Insulation Non-Insulated
Mounting Type Through Hole, Right Angle
Features UL Approved
Contact Material Brass
Contact Finish Tin
Standard Package 10 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.90.4000
Win Source Part Number 546129-4903
Ultra Librarian 3D Model Ultra Librarian 4903 CAD Model

Description

The 546129-4903 is a male quick disconnect connector from Keystone Electronics. It is a solder termination type connector with a tin contact finish. The 546129-4903 is a male quick disconnect connector from Keystone Electronics. It is a solder termination type connector with a tin contact finish.

  • Termination Type: Solder
  • Contact Finish: Tin
  • Insulation: Non-insulated
  • Tab Width: 0.110" (2.79mm)
  • Tab Thickness: 0.020" (0.51mm)
  • Mounting: Through hole, Right angle
  • Approvals: UL
  • Standard Package: 10 pcs
  • Win Source Part Number: 546129-4903
