Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Relays
Manufacturer Kemet
Series EC2
Packaging Tube
Relay Type General
Coil Type Non Latching
Coil Current 8.3mA
Coil Voltage 24VDC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 2A
Switching Voltage 250VAC, 220VDC - Max
Turn On Voltage (Maximum) 18 VDC
Turn Off Voltage (Minimum) 2.4 VDC
Operate Time 2ms
Release Time 1ms
Mounting Style Through Hole
Termination Style PC Pin
Contact Material Silver Alloy, Gold Alloy
Coil Power 200 mW
Coil Resistance 2.88 kOhms
Operating Temperature Range -40°C ~ 85°C
Win Source Part Number 773642-EC2-24NU
Popularity Medium
Supply and Demand Status Limited
Family Name EC2
Introduction Date August 29, 2013
ECCN EAR99
Country of Origin Japan
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian EC2-24NU CAD Model

Description

The Kemet EC2 series relay is a general-purpose, non-latching DPDT relay designed for use in a variety of electronic equipment.

  • Coil Voltage: 24VDC
  • Contact Rating: 2A
  • Mounting Type: Through Hole
  • Coil Resistance: 2.88 kOhms
  • Coil Current: 8.3mA
  • Operating Temperature Range: -40°C to 85°C
  • Contact Switching Voltage: 250VAC or 220VDC
