IXFA80N25X3 Real Image IXFA80N25X3 Real Image
Same model may have multiple batches, images only for reference.
IXFA80N25X3 Real Image IXFA80N25X3 Real Image
IXFA80N25X3 Real Image IXFA80N25X3 Real Image
Same model may have multiple batches, images only for reference.

IXFA80N25X3

Part No IXFA80N25X3
Manufacturer IXYS
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 250V 80A TO263AA / N-Channel 250 V 80A (Tc) 390W (Tc) Surface Mount TO-263 (D2Pak)
Datasheet
IXFA80N25X3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Single
Mfr IXYS
Series HiPerFET™, Ultra X3
Package Tube
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 250 V
Current - Continuous Drain (Id) @ 25°C 80A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Max) @ Id, Vgs 16mOhm @ 40A, 10V
Vgs(th) (Max) @ Id 4.5V @ 1.5mA
Gate Charge (Qg) (Max) @ Vgs 83 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 5430 pF @ 25 V
Power Dissipation (Max) 390W (Tc)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting SMD (SMT)
Supplier Device Package TO-263 (D2Pak)
Package / Case TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Base Product Number IXFA80
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Standard Package 50
Win Source Part Number 981910-IXFA80N25X3
Ultra Librarian 3D Model Ultra Librarian IXFA80N25X3 CAD Model

Description

The IXYS IXFA80N25X3 is an N-channel MOSFET. IXYS manufactures it.

  • Drain-to-Source Voltage: 250V
  • Continuous Drain Current: 80A @ 25°C
  • Rds On: 16mOhm @ 40A and 10V
  • Gate Charge: 83nC @ 10V
  • Package: TO-263-3, D2Pak
  • Operating Temperature: -55°C to 150°C
