PAH100S48-5

Name: PAH100S48-5
Brand: TDK-Lambda Americas Inc.
SKU: 652463
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	PAH100S48-5
Manufacturer	TDK-Lambda Americas Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 5V 100W / Isolated Module DC DC Converter 1 Output 5V 20A 36V - 76V Input
Datasheet	PAH100S48-5 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	TDK-Lambda Americas Inc.
Series	PAH (100W)
Package	Bulk
Product Status	Obsolete
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	36V
Voltage - Input (Max)	76V
Voltage - Output 1	5V
Current - Output (Max)	20A
Power (Watts)	100 W
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Features	Remote On/Off, OCP, OTP, OVP
Temperature Range - Operating	-40°C ~ 100°C
Efficiency	84%
Mounting Type	Through Hole
Package / Case	9-DIP Module
Size / Dimension	2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm)
Control Features	Enable, Active Low
Standard Package	1 pcs
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.40.9580
California Prop 65	Warning Information
Win Source Part Number	652463-PAH100S48-5
Ultra Librarian 3D Model	Ultra Librarian PAH100S48-5 CAD Model

Alternative Products

Description

The PAH100S48-5 is a 100W isolated module DC-DC converter designed for board mount applications.

Features: Remote On/Off, Overcurrent Protection (OCP), Overtemperature Protection (OTP), Overvoltage Protection (OVP)
Size: 2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm)
Application: ITE (Commercial)
Power: 100W
Voltage Isolation: 1.5 kV
Output: Single
Current (Max): 20A
Output Voltage: 5V
Efficiency: 84%
Operating Temperature: -40°C to 100°C
Manufacturer: TDK-Lambda Americas Inc.
Status: Obsolete
Series: PAH
