IRF9358TRPBF Real Image IRF9358TRPBF real image11743 IRF9358TRPBF Real Image1 IRF9358TRPBF Real Image2
Same model may have multiple batches, images only for reference.
IRF9358TRPBF Real Image IRF9358TRPBF real image11743 IRF9358TRPBF Real Image1 IRF9358TRPBF Real Image2
IRF9358TRPBF Real Image IRF9358TRPBF real image11743 IRF9358TRPBF Real Image1 IRF9358TRPBF Real Image2
Same model may have multiple batches, images only for reference.

IRF9358TRPBF

Part No IRF9358TRPBF
Manufacturer Infineon Technologies
Catalog FETs - Arrays
Description Charge and Discharge Switch for Notebook PC Battery Application | MOSFET 2P-CH 30V 9.2A 8SOIC / Trans MOSFET P-CH 30V 9.2A 8-Pin SOIC N T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel
Transistor Polarity 2 P-Channel (Dual)
FET Feature Logic Level Gate
Vds - Drain-Source Breakdown Voltage 30V
Id - Continuous Drain Current 9.2A
Rds On (Maximum) at Id, Vgs 16.3mOhm at 9.2A, 10V
Gate Source Voltage(th) (Maximum) at Id 2.4V at 25μA
Gate Charge (Qg) (Maximum) at Vgs 38nC at 10V
Input Capacitance (Ciss) (Maximum) at Vds 1740pF at 25V
Maximum Power 2W
Temperature Range - Operating -55°C ~ 150°C
Mounting Style SMD
Manufacturer Package 8-SOIC
Supplier Device Package 8-SO
Family Part Number IRF9358PBF
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1187429-IRF9358TRPBF
Manufacturer Homepage www.irf.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name IRF9358
Introduction Date January 02, 2011
ECCN EAR99
Country of Origin China, Thailand
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian IRF9358TRPBF CAD Model

Description

The IRF9358TRPBF is a product of Infineon Technologies.

  • Manufacturer: Infineon Technologies
  • Supply and Demand Status: Balanced
  • Manufacturer Homepage: www.irf.com
  • Packaging: Reel
  • Mounting Style: SMD
  • Family Name: IRF9358
  • Temperature Range: -55°C to 150°C
  • Estimated EOL Date: 2027
  • Halogen-Free Compliant: Yes
  • Common-Used Part: Yes
  • Vds - Drain-Source Breakdown Voltage: 30V
  • Id - Continuous Drain Current: 9.2A
  • Rds On (maximum) @ Id, Vgs: 16.3mOhm @ 9.2A, 10V
  • Gate Source Voltage(th) (maximum) @ Id: 2.4V @ 25μA
  • Gate Charge (Qg) (maximum) @ Vgs: 38nC @ 10V
  • Input Capacitance (Ciss) (maximum) @ Vds: 1740pF @ 25V
