IR2155PBF Real Image IR2155PBF Real Image
Same model may have multiple batches, images only for reference.
IR2155PBF Real Image IR2155PBF Real Image
IR2155PBF Real Image IR2155PBF Real Image
Same model may have multiple batches, images only for reference.

IR2155PBF

Part No IR2155PBF
Manufacturer Infineon Technologies
Catalog PMIC - Gate Drivers
Description SELF-OSCILLATING HALF-BRIDGE DRIVER | IC DRIVER HALF BRIDGE OSC 8DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Tube
Status Obsolete
Driven Configuration Half-Bridge
Channel Type Synchronous
Number of Drivers 2
Gate Type IGBT, N-Channel MOSFET
Supply Voltage (V) 10V ~ 20V
Current - Peak Output (Source, Sink) 250mA, 500mA
Input Type RC Input Circuit
High Side Voltage - Max (Bootstrap) 600V
Rise / Fall Time 80ns, 45ns
Temperature Range - Operating -40°C ~ 150°C
Mounting Style Through Hole
Manufacturer Package 8-DIP
Supplier Device Package 8-PDIP
Family Part Number IR2155PBF
Manufacturer Pack Quantity 50
MSL Level 1 (Unlimited)
Win Source Part Number 1186636-IR2155PBF
Manufacturer Homepage www.irf.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IR2155PBF CAD Model

Description

The IR2155PBF from Infineon Technologies is a half-bridge driver IC designed for use in synchronous channel type applications.

  • Input Type: RC input circuit
  • Drivers: Two drivers
  • Gate Type: IGBT and N-Channel MOSFET
  • High Side Voltage Maximum Bootstrap: 600V
  • Current Peak Output (source, sink): 250mA and 500mA, respectively
  • Package: 8-PDIP package
  • Status: Obsolete
  • Supply and Demand Status: Limited
  • Temperature Range for Operating: -40°C to 150°C
  • Rise/Fall Time: 80ns and 45ns
