IR1150ISTRPBF

Part No IR1150ISTRPBF
Manufacturer Infineon Technologies
Catalog PMIC - PFC (Power Factor Correction)
Description Power Factor Correction Controller 0.175mA 50kHz to 200kHz 8-Pin SOIC T/R / IC PFC CONTROLLER CCM 8-SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Obsolete(EOL)
Mode Continuous Conduction (CCM)
Frequency - Switching 200kHz
Current - Startup 175μA
Supply Voltage - Operating 15 V to 20 V
Temperature Range - Operating -25°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 040657-IR1150ISTRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 2,500
Family Name IR1150
Introduction Date March 02, 2005
ECCN EAR99
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian IR1150ISTRPBF CAD Model

Description

IR1150ISTRPBF from Infineon Technologies is a PMIC device used in power factor correction designs, making it relevant for engineers developing offline power supplies, industrial power conversion stages, and energy-conscious AC-DC systems. In PFC applications, parts in this category are typically selected to help improve input current shaping, support regulatory goals, and enhance overall power conversion performance in end equipment. This component is positioned for designers who need a dedicated solution within a PFC control architecture for applications such as appliances, lighting power supplies, consumer electronics, and industrial power modules. The current lifecycle status for IR1150ISTRPBF is information not available, so design teams should confirm availability and long-term support directly with Infineon Technologies or authorized distribution channels before committing to new programs. RoHS compliance information is also not available in the provided data and should be verified using the latest manufacturer datasheet, compliance declaration, or distributor documentation.
