Products specifications Report Issue?

Category Connectors, Interconnects>Backplane Connectors>Specialized
Mfr HARTING
Series -
Package Bulk
Product Status Obsolete
Connector Usage Backplane-to-Daughtercard
Connector Type Receptacle, Female Sockets
Connector Style Coax
Number of Positions 6
Number of Positions Loaded All
Pitch -
Number of Rows -
Number of Columns -
Mounting Type Through Hole
Termination Press-Fit
Contact Layout, Typical 6 Coax
Features Board Guide
Contact Finish Gold
Contact Finish Thickness -
Color Natural
Current Rating (Amps) 3A
Material Flammability Rating UL94 V-0
Temperature Range - Operating -55°C ~ 125°C
Voltage Rating -
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4010
Standard Package 20 pcs
Win Source Part Number 1381041-07111000023
Ultra Librarian 3D Model Ultra Librarian 07111000023 CAD Model

Description

The Specialized Backplane Connector is a high-quality and reliable connector for backplane-to-daughtercard applications. This connector, designed for through-hole mounting, features press-fit termination for secure and stable connections. With a current rating of 3A and a temperature range of -55°C to 125°C, this connector is suitable for a wide range of applications and can withstand harsh environmental conditions. The connector has a natural color and features a board guide for easy installation and alignment. The package includes 20 pieces, ensuring you have an ample supply for your needs. The HARTING Specialized Backplane Connector is an obsolete product but remains a reliable choice for your backplane-to-daughtercard connectivity needs.

  • Application: Backplane-to-Daughtercard
  • Mounting Type: Through Hole
  • Termination: Press-Fit
  • Current Rating: 3A
  • Temperature Range: -55°C to 125°C
  • Color: Natural
  • Features: Board Guide
  • Package Quantity: 20
  • Manufacturer: HARTING
