1760H Real Image
Same model may have multiple batches, images only for reference.

1760H

Part No 1760H
Manufacturer Hammond Manufacturing
Catalog Audio Transformers
Description TRANSFORMER TUBE GUITAR AMP / 6.6kCT Impedance Primary Ohms 4, 8, 16 Impedance Secondary Ohms 40.62:1, 28.72:1, 20.31:1 Audio Transformer 70Hz ~ 15kHz Chassis Mount
Datasheet
1760H Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Transformers>Audio Transformers
Mfr Hammond Manufacturing
Series 1760
Package Box
Impedance - Primary (Ohms) 6.6kCT
Impedance - Secondary (Ohms) 4, 8, 16
DC Resistance (DCR) - Primary 347.8Ohm
DC Resistance (DCR) - Secondary 686mOhm, 803mOhm, 1.157Ohm
Transformer Type Push-Pull Audiophile, Ultra-Linear - Tube Output
Frequency Range 70Hz ~ 15kHz
Frequency Response ±1dB
Power Level 20W
Mounting Type Chassis Mount
Dimension 3.710" L x 2.400" W (94.23mm x 60.96mm)
Height - Seated (Max) 2.371" (60.22mm)
Termination Style Wire Leads
Weight 0.625 lb (283.5 g)
Base Product Number 1760
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.31.4035
Other Names 1760H-ND,HM1562
Standard Package 1
Win Source Part Number 1041163-1760H
Ultra Librarian 3D Model Ultra Librarian 1760H CAD Model

Description

This push-pull audiophile, ultra-linear - tube output transformer from the 1760 series is made for audio transformers.

  • Frequency Range: 70Hz ~ 15kHz
  • Power Level: 20W
  • Termination Style: Wire Leads
  • Dimension: 3.710" L x 2.400" W (94.23mm x 60.96mm)
  • Impedance - Primary (Ohms): 6.6kCT
  • Impedance - Secondary (Ohms): 4, 8, 16
  • DC Resistance (DCR) - Primary: 347.8Ohm
  • DC Resistance (DCR) - Secondary: 686mOhm, 803mOhm, and 1.157Ohm
  • Frequency Response: ±1dB
  • Weight: 0.625 lb
  • Package: Box
  • Standard Package: 1
  • MSL Level: Not Applicable
  • REACH Status: REACH Unaffected
  • HTSUS: 8504.31.4035
  • Manufacturer: Hammond Manufacturing
  • Other Names: 1760H-ND and HM1562
  • Base Product Number: 1760
