Same model may have multiple batches, images only for reference.
107X Real Image
Same model may have multiple batches, images only for reference.

107X

Part No 107X
Manufacturer Hammond Manufacturing
Catalog Audio Transformers
Description TRANSFORMER AUDIO 100KCT/1KCT / 100kCT Impedance Primary Ohms 1kCT Impedance Secondary Ohms 10:1 Audio Transformer 300Hz ~ 50kHz Through Hole
Datasheet
107X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Transformers>Audio Transformers
Manufacturer Hammond Manufacturing
Packaging Bulk
Impedance - Primary (Ohms) 100kCT
Impedance - Secondary (Ohms) 1kCT
DC Resistance (DCR) - Primary 3.66kOhm
DC Resistance (DCR) - Secondary 75Ohm
Transformer Type Miniature Epoxy Potted
Frequency Range 300Hz ~ 50kHz
Frequency Response ±1.5dB
Voltage - Isolation 500Vrms
Power Level 150mW
Mounting Through Hole
Size / Dimension 0.630" L x 0.586" W (16.00mm x 14.88mm)
Height - Seated (Max) 0.630" (16.00mm)
Termination Style PC Pin
Weight 0.02 lb (9.07 g)
RoHS Status ROHS3 Compliant
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.31.4035
Other Part Number 107XHM-ND,107XHM,HM2379
Standard Package 1
Win Source Part Number 1329348-107X
Ultra Librarian 3D Model Ultra Librarian 107X CAD Model

Description

The 107X is an audio transformer produced by Hammond Manufacturing.

  • Manufacturer: Hammond Manufacturing
  • Type: Audio Transformer
  • Construction: Miniature epoxy potted transformer
  • Termination Style: PC Pin
  • Voltage Isolation: 500Vrms
  • Power Level: 150mW
  • Popularity: Low popularity
  • Supply and Demand Status: Limited
