148D Hammond Manufacturing – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

148D

Part No 148D
Manufacturer Hammond Manufacturing
Catalog Audio Transformers
Description AUDIO XFMR 200K / 1K TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Impedance - Primary (Ohms) 200k
Impedance - Secondary (Ohms) 1k
DC Resistance (DCR) - Primary 1.76kOhm
DC Resistance (DCR) - Secondary 6.2Ohm
Transformer Type Economical Open Type
Frequency Range 200Hz ~ 15kHz
Frequency Response ±1dB
Insertion Loss 0.5dB
Power Level 3mW
Mounting Type Through Hole
Size / Dimension 0.820" L x 0.680" W (20.83mm x 17.27mm)
Height - Seated (Max) 0.690" (17.53mm)
Termination Style PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1511074-148D
Ultra Librarian 3D Model Ultra Librarian 148D CAD Model
