NC7WV17P6X Real Image NC7WV17P6X Real Image
Same model may have multiple batches, images only for reference.
NC7WV17P6X Real Image NC7WV17P6X Real Image
NC7WV17P6X Real Image NC7WV17P6X Real Image
Same model may have multiple batches, images only for reference.

NC7WV17P6X

Part No NC7WV17P6X
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Buffers, Drivers, Receivers, Transceivers
Description Schmitt Trigger Buffer 2-CH Non-Inverting CMOS 6-Pin SC-70 T/R / IC BUFF DL SCHMT TRIG SC70-6
Datasheet
NC7WV17P6X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type Buffer, Non-Inverting
Number of Elements 2
Number of Bits per Element 1
Input Type Schmitt Trigger
Output Type Push-Pull
Current - Output High, Low 24mA, 24mA
Supply Voltage - Operating 0.9 V to 3.6 V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package SC-70-6
Win Source Part Number 059915-NC7WV17P6X
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Industrial
Quantity per package 3k pcs
Family Name NC7WV17
Introduction Date May 23, 2003
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian NC7WV17P6X CAD Model

Description

The Fairchild/ON Semiconductor NC7WV17P6X is a buffer, non-inverting logic gate that has two elements and one bit per element.

  • Output type: push-pull
  • Input type: Schmitt Trigger
  • Type: surface mount logic gate
  • Maximum operating voltage: 3.6V
  • Current rating for output high and low: 24mA
  • Operating Temperature: -40°C to 85°C
  • Ideal for use in: industrial applications such as data processing, signal conditioning, and other electronic circuits that require a high-quality logic gate
