FAN7842MX Real Image FAN7842MX real image3991 FAN7842MX Real Image
Same model may have multiple batches, images only for reference.
FAN7842MX Real Image FAN7842MX real image3991 FAN7842MX Real Image
FAN7842MX Real Image FAN7842MX real image3991 FAN7842MX Real Image
Same model may have multiple batches, images only for reference.

FAN7842MX

Part No FAN7842MX
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - Gate Drivers
Description IC DRIVER HIGH/LOW GATE 8-SOP / Driver 200V 0.65A 2-OUT High and Low Side Full Brdg/Half Brdg Non-Inv 8-Pin SOP T/R
Datasheet
FAN7842MX Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Driven Configuration Half-Bridge
Channel Type Independent
Number of Drivers 2
Gate Type IGBT, N-Channel MOSFET
Supply Voltage - Operating 10 V to 20 V
Logic Voltage - VIL, VIH 0.8V, 2.9V
Current - Peak Output (Source, Sink) 350mA, 650mA
Input Type Non-Inverting
High Side Voltage - Max (Bootstrap) 200V
Rise and Fall Time 60ns, 30ns
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOP
Win Source Part Number 066870-FAN7842MX
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 3k pcs
Family Name FAN7842
Introduction Date January 16, 2006
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian FAN7842MX CAD Model

Description

FAN7842MX High-Efficiency Gate Driver

The FAN7842MX is an advanced gate driver designed for optimal performance in power management applications. It features high-speed operation, robust input/output isolation, and low power consumption, making it ideal for driving power MOSFETs and IGBTs in various switching power applications.

  • High-Speed Operation: Ensures efficient power switching with minimal delay times.
  • Low Power Consumption: Enhances energy efficiency in battery-powered applications.
  • Robust Isolation: Provides reliable input/output separation for enhanced safety in critical applications.

Applications

  • Switched-Mode Power Supplies (SMPS)
  • Industrial Motor Drives
  • Power Factor Correction (PFC) Circuits
  • Uninterruptible Power Supplies (UPS)
