2N7002W Real Image 2N7002W real image239 2N7002W real image240
Same model may have multiple batches, images only for reference.
2N7002W Real Image 2N7002W real image239 2N7002W real image240
2N7002W Real Image 2N7002W real image239 2N7002W real image240
Same model may have multiple batches, images only for reference.

2N7002W

Part No 2N7002W
Manufacturer Fairchild/ON Semiconductor
Catalog FETs - Single
Description Trans MOSFET N-CH 60V 0.115A 3-Pin SC-70 T/R / MOSFET N-CH 60V 115MA SOT-323
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Fairchild Semiconductor
Standard Package 1
Category Discrete Semiconductor Products
Family FETs - Single
Packaging Reel
FET Type MOSFET N-Channel Metal Oxide
FET Feature Standard
Drain to Source Voltage (Vdss) 60V
Current - Continuous Drain (Id) @ 25°C 115mA (Ta)
Rds On (Max) @ Id Vgs 7.5 Ohm @ 50mA 5V
Vgs(th) (Max) @ Id 2V @ 250µA
Input Capacitance (Ciss) @ Vds 50pF @ 25V
Power - Max 200mW
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Style SMD/SMT
Package SC-70 SOT-323
Manufacturer Device Package SC-70
Catalog N-Channel Logic Level Gate FETs
Win Source Part Number 095707-2N7002W
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Defence, Military & Aerospace, Automotive
Family Name 2N7002W
Introduction Date April 25, 2007
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian 2N7002W CAD Model

Description

Overview

The 2N7002W is a versatile, low-voltage N-channel MOSFET renowned for its high performance in switching applications. Its compact form factor and low on-resistance make it suitable for modern electronic devices.

Applications

  • Battery-Powered Devices
  • Consumer Electronics
  • DC-DC Converters
  • Motor Controllers

Features and Benefits

  • SOT-323 package offering flexibility and space efficiency.
  • Enhanced thermal stability ensures reliable operation.
  • Low threshold voltage supports lower power designs.
  • High-speed switching reduces overall power consumption.
